HICLOVER is growing brand for environmental protection field, and market share with most of Africa, Middle East, Southeast Asia countries and part of North America, Europe territory. We are trusted partner for governmental organizations, non-profit organizations, international contractors, logistics organizations, military, pet cremation business owners, etc. We have export experience more than 40 countries, including war zone like Iraq, Afghanistan, Somalia, South Sudan. Mobile: +86-13813931455(WhatsApp) Website: www.hiclover.com Email: [email protected] Email: [email protected]
Dual heat burners and dual chamber incinerator Burning capacity up to 30 Kg per hour with wet scrubber
Dual heat burners and dual chamber incinerator Burning capacity up to 30 Kg per hour
Main Product List
Primary Combustion Chamber(Main body stainless steel)
Secondary Combustion Chamber(Main body stainless steel)
Mix-Combustion Chamber
Wet Scrubber( Washing Tower)(Main body stainless steel)
Incinerator Control Case
Chimney:5.0Meters Stainless Steel
Italy gas burner: 02 sets
Oil Tank (if oil fuel): 100Liters
|
Model |
YD |
|
Feed Capacity |
Average 50 kgs per feeding |
|
Burning Rate |
Average 30 kgs per hour |
|
Burning Time per Feed |
2 hours |
|
Voltage |
380V |
|
Power |
6 Kw |
|
Fuel |
Natural Gas |
|
Burner |
|
|
Feed Mode |
Manual |
|
Fuel consumption (Oil) |
10.2-20.0 Kgs/Hour |
|
Fuel consumption (Gas) |
12.2 |
|
External Dimensions |
170 x 140 x |
|
Internal Dimensions |
55 x 55 x |
|
Waste combustion chamber |
250Liters |
|
Post Combustion Chamber |
140Liters |
|
Oil Tank Capacity |
100 Liters |
|
Door Opening |
38 x |
|
Chimney |
|
|
Gross Weight |
3300kgs |
|
Chamber Material |
Refractory Concrete |
|
Max. Heat Value |
200,000Kcal/Hr. |
|
Operation Technical Specifications |
|
|
Solid Chamber temperature |
|
|
Gas Chamber temperature |
|
|
Chamber Anti-Rate |
|
|
Residency time |
2.0 Sec. |
|
Burning efficiency |
＞98% |
|
Waste Lower Calorific Power |
3000Kcal |
Water showering cyclone air cleaner Stain less steel 304 grade sheet for water scrub chamber
